1000T Composite Forming Hydraulic Press

Min. Order:
Chat Now
  • Product Description
Product Attributes

Model No.Y36L


FeatureHigh Efficiency





Warranty12 Months

Supply Ability & Additional Informations


Place of OriginChina

Supply Ability1set/5months


Product characteristic:

This series of Hydraulic Press is mainly applicable to the pressing and forming process of plastic (fiberglass) products such as SMC, BMC, DMC, GMT, lft-d, etc. there are two kinds of special high rigidity fuselage structures of fiberglass hydraulic press with four columns and frame. It has the process of multi-stage preloading, pressurization and micro opening. Soft landing technology, fast and slow conversion without impact, protect the mold, greatly improve the service life of the mold and equipment, fast and slow adjustable preloading technology. According to the technical requirements of the product formula, the fluidity can be set by numerical control during the prepressing, which is more suitable for the forming of large-area, left-right, upper and lower structure complex parts. The technology of mold opening and air-jet demoulding can be set, and the surface quality of hot pressing die products can be well guaranteed. The process can solve the other technical problems, such as mold expanding, rough surface of products and difficult demoulding of products. This series of hydraulic press is the key equipment for the manufacture of FRP products in the fields of aerospace, rail transit, ship, automobile, architecture, petrochemical, energy, electronics, sports and other industries. Nominal force: 1000kn-30000kn.

Composite Forming Hydraulic Press1591161137(1)Composite Forming Hydraulic Press


Composite forming

Looking for ideal Composite Forming Hydraulic Manufacturer & supplier ? We have a wide selection at great prices to help you get creative. All the SMC BMC DMC GMT LFT-D Forming are quality guaranteed. We are China Origin Factory of Forming Of Complex Parts. If you have any question, please feel free to contact us.

Product Categories : Hydraulic Press For Composite Forming > H Frame Composite Forming Hydraulic Press
